Jenkins is the way to make my life in the test core team great again

Run Tests and Verify Project Quality Before Merging in Production

Submitted By Jenkins User Martin Pokorny
Shorter release cycles and easier roll-out of new projects in safer environments made easier with the help of Jenkins.
Organization: Germany-based software and automation
Industries: HMI / Scada
Programming Languages:
Platform: : Android, Docker or Kubernetes, Linux, Windows, Siemens HMI displays
Build Tools: CMake
Community Support: websites & blogs, Spoke with colleagues and peers

WinCC OA project continues integration with Jenkins and WinCC OA Test Framework.

Background: We are a software house developing and selling automation software. Our product, a SCADA system (SCADA / HMI), is called SIMATIC WinCC Open Architecture and controls, among other things, the New York subway, tunnels in Hong Kong, pipelines in Russia, CERN in Geneva, and many thousands of different technical processes. Our solutions are mainly suited for traffic, water, energy, oil & gas, building automation industry, and research.

To create and execute a test of WinCC OA projects, we have developed our own Test framework. Now we have more than 100,000 test cases, and the execution time takes over 40 hours on a developer machine. We looked at Jenkins integrations to help us speed up the testing of changes in feature branches. We also wanted to inform the developers about side effects as soon as possible and quickly get our QA department an overview of the current quality of the product. This would make it possible to decrease release cycles and safely roll out new projects.Goals: Make static and dynamic tests of any WinCC OA projects on all currently supported platforms. Run tests on SW changes and verify the project quality before changes are merged in the production branch. Add metrics and code coverage for our QAs to be fit for security and safety audits. Use lockable resources to eliminate the amount of HW (PLCs) and stabilize tests.

Solution & Results: We use Jenkins in 2 instances. The first one builds the application, and after a successful build and unit test, it sends a trigger to the second Jenkins instance, which deploys WinCC to many test nodes (~250 in use) and starts all necessary tests. We then run primitive unit, application, and integration tests in a few hours.

Docker integration decreases this time rapidly. To stabilize our driver test, we use lockable resources. The Jenkins integration of multi-branch Pipelines allows testing of developer changes in just a few minutes and before they are merged in the production branch. Jenkins plugins like Git or JUnit eliminate programming time and maintenance. But the highlight is Groovy integration. In the scripted pipeline, there are no limitations for us.

I doubt there is a tool as helpful as Jenkins for CI/CD integration in complex environments. Many thanks to the Jenkins community.
profile picture
Martin Pokorny, Senior Software Developer and Key Software Tester

Results are as follows:

  • Improve product quality and Spare time for patch releases
  • Run complex test with manual execution takes over days in few hours
  • Test any supported platforms
  • Inform developer about side effects
  • Inform QA department about product quality any time
